Basic Info.
Finish
Plain, Black, Zp, Yzp, HDG, Dacromet, Geomet, etc.
Used
Machine, Chemical, Industial
Mechanical Properties
GB3098.2
Transport Package
Bulk/Boxes in Cartons, Bulk in Polybags/-Buckets
Origin
Zhejiang Province.
Product Description
Product Description
| Product name | HEX NUTS |
| Standard | ANSI B18.2.4.1M |
| Size | M5-M36 |
| Class | CL.5/10 |
| Finish | Z.P., B.Z.P.,PLAIN, BLACK, H.D.G., dacromet, geomet, nickle plated, mechanical zinc plated,etc. |
| Packing | bulk/boxes in cartons, bulk in poly bags/-buckets, etc |
| Pallet | solid wood pallet, plywood pallet, ton box/bag, etc. |
| Mechanical Properties: | ISO898.2 |
Size Chart
| ANSI B18.2.4.1M-1999 |
| Metric hexagon nuts |
| |
| unit:mm |
| d | P | s | m |
| max | min | max | min |
| M5 | 0.8 | 8 | 7.78 | 4.7 | 4.4 |
| M6 | 1 | 10 | 9.78 | 5.2 | 4.9 |
| M8 | 1.25 | 13 | 12.73 | 6.8 | 6.44 |
| M10 | 1.5 | 15 | 14.73 | 9.1 | 8.7 |
| M10 | 1.5 | 16 | 15.73 | 8.4 | 8.04 |
| M12 | 1.75 | 18 | 17.73 | 10.8 | 10.37 |
| M14 | 2 | 21 | 20.67 | 12.8 | 12.1 |
| M16 | 2 | 24 | 23.67 | 14.8 | 14.1 |
| M20 | 2.5 | 30 | 29.16 | 18 | 16.9 |
| M24 | 3 | 36 | 35 | 21.5 | 20.2 |
| M30 | 3.5 | 46 | 45 | 25.6 | 24.3 |
| M36 | 4 | 55 | 53.8 | 31 | 29.4 |
Free Samples for standard fastener from Jiaxing City Qunbang Hardware
QBH Promise:
1. High quality
2. Competitive price
3. The shortest delivery
4. The fastest response
5. The best service
FAQ
Q:Are you a factory or trading company?
A: We are factories, mainly producing fasteners, such as nuts, bolts, screws and rods, and meanwhile, we also manage other hardware products.
Q: Where is your factory located? How can I visit there?
A: Our factory is located in Jiaxing City, Zhejiang Province with a good location and convenient transportation, which is next to Shanghai Port, Ningbo Port and Zhapu Port.
Q: How does your factory do regarding quality control?
A: "Quality is priority" we supervise each production link and we always attach great importance to quality controlling from the beginning to the end.
Awaiting for your kind inquiry! Thanks & best regards!
For more information: http://qbfastener.en.made-in-china.com & http://qbfastener.en.made-in-china.com
