Basic Info.
Steel Grade
Low Carbon and Medium Carbon Steel
Transport Package
Carton, Polybag, Barrel
Origin
Zhejiang Province.
Product Description
Product Description
| Product name | Metal Lock Nuts |
| Standard | DIN929 |
| Size | M3-M16 |
| Grade | 5.8 |
| Finish | PLAIN, Zinc Plated |
| Material | Carbon Steel |
| Packing | Carton, Polybag, Barrel |
| Pallet | solid wood pallet, plywood pallet, ton box/bag |
Free Samples for standard fastener from Jiaxing City Qunbang Hardware
Dimension:
| DIN929-2000 |
| | unit:mm |
| D | P | h1 | h2 | m | s | dy |
| M3 | 0.5 | 0.55 | -0.1 | 0.25 | -0.1 | 3 | 7.5 | 4.5 |
| M4 | 0.7 | 0.65 | 0.35 | 3.5 | 9 | 6 |
| M5 | 0.8 | 0.7 | 0.4 | 4 | 10 | 7 |
| M6 | 1 | 0.75 | -0.15 | 0.4 | 5 | 11 | 8 |
| M8 | 1/1.25 | 0.9 | 0.5 | -0.15 | 6.5 | 14 | 10.5 |
| M10 | 1/1.25/1.5 | 1.15 | 0.65 | 8 | 17 | 12.5 |
| M12 | 1.25/1.5/1.75 | 1.4 | -0.2 | 0.8 | -0.2 | 10 | 19 | 14.8 |
| M14 | 1.5/2 | 1.8 | 1 | 11 | 22 | 16.8 |
| M16 | 1.5/2 | 1.8 | 1 | 13 | 24 | 18.8 |
