Basic Info.
Material
High Strength Steel
Surface Finish
Black Oxide
Mechanical Properties
ISO898.1
Transport Package
Carton, Polybag, Barrel
Origin
Zhejiang Province.
Product Description
Product Description:
| F10T |
| Standard | JISB1186 |
| Size | M12-M36 |
| Finish | Black oxide |
| Grades | 10.9 |
| Packing | Carton, Polybag, Barrel |
| Pallet | solid wood pallet, plywood pallet, ton box/bag, etc. |
| Material | High Strength Steel |
| Mechanical Properties | ISO898.1 |
Free Samples for standard fastener from Jiaxing City Qunbang Hardware
F10T
unit:mm
| d | P | b | ds | k | s |
| max | min | max | max | min | max | min |
| M12 | 1.75 | 23 | 21 | 15.2 | 8.45 | 7.55 | 22 | 21.16 |
| M16 | 2 | 28 | 26 | 19.2 | 10.75 | 9.25 | 27 | 26.16 |
| M20 | 2.5 | 33 | 31 | 24 | 13.9 | 12.1 | 32 | 31 |
| M22 | 2.5 | 34 | 32 | 26 | 14.9 | 13.1 | 36 | 35 |
| M24 | 3 | 37 | 34 | 28 | 15.9 | 14.1 | 41 | 40 |
| M27 | 3 | 39 | 37 | 32 | 17.9 | 16.1 | 46 | 45 |
| M30 | 3.5 | 42 | 40 | 35 | 20.05 | 17.95 | 50 | 49 |
| M36 | 4 | 50 | 48 | 41 | 24.05 | 21.95 | 60 | 58.8 |
We Promise:
1. High quality
2. Competitive price
3. The shortest delivery
4. The fastest response
5. The best service
FAQ
Q:Are you a factory or trading company?
A: We are factories, mainly producing fasteners, such as nuts, bolts, screws and rods, and meanwhile, we also manage other hardware products.
Q: Where is your factory located? How can I visit there?
A: Our factory is located in Jiaxing City, Zhejiang Province with a good location and convenient transportation, which is next to Shanghai Port, Ningbo Port and Zhapu Port.
Q: How does your factory do regarding quality control?
A: "Quality is priority" we supervise each production link and we always attach great importance to quality controlling from the beginning to the end.
Awaiting for your kind inquiry! Thanks & best regards!
